uplinjevalne rešetke
- potreben ND, ki ni vključen v naši spletni trgovini, je seveda mogoče naročiti, vendar verjetno zahteva posvetovanje - podrobnejše tehnične informacije info@deltastav.si
|
Vrsta kotla ATMOS |
Število rešetk v kotlu |
B |
A – 24 mm |
A – 20 mm |
AO – 24 mm |
|
C15S, KC16S |
3 |
2x C0010 |
1x C0008 |
|
|
|
C18, C18S – izdelano do 8/2016 |
7 |
Novo izvedbo rešetk: 2x C0027 Stari rošt: |
5x C0028
5x C0016 |
|
|
|
C18S, C18SP(L) proizvedeno od 9/2016 do 5/2017 |
5 |
2x C0010 |
1x C0008 |
|
2x C0083* |
|
C18S, C18SP(L) – izdelani od 6/2017 |
5 |
2x C0010 |
3x C0008 |
|
|
|
KC35S |
6 |
2x C0010 |
4x C0008 |
|
|
|
AC32SP(L), KC32SP(L) |
6 |
2x C0010 |
3x C0008 |
1x C0009 |
|
|
C25ST, C25SP(L) |
6 |
2x C0010 |
2x C0008 |
|
2x C0083* |
|
C20, C20S |
9 |
Novo izvedbo rešetk: 2x C0027 Stari rošt: |
6x C0028
6x C0016 |
1x C0029
1x C0019 |
|
|
AC35S |
9 |
2x C0010 |
6x C0008 |
1x C0009 |
|
|
C30, C30S |
10 |
Novo izvedbo rešetk: 2x C0027 Stari rošt: |
7x C0028
7x C0016 |
1x C0029
1x C0019 |
|
|
AC45S, KC45S |
10 |
2x C0010 |
7x C0008 |
1x C0009 |
|
|
C32ST |
8 |
2x C0010 |
3x C0008 |
|
3x C0083* |
|
C40, C40S, C50S |
11 |
2x C0010 |
8x C0008 |
1x C0009 |
|
|
DC14R |
4 |
4x C0066 |
|
|
|
|
DC24RS, DC30RS |
3 |
3x C0066 |
|
|
|
|
Vrsta kotla ATMOS |
Število rešetk v kotlu |
Dolžina rešetkaste cevi |
Rostna cev |
Tesnilo za rešetkaste cevi |
|
C15S, KC16S |
3 |
390 |
C0077 |
S0940 |
|
C18, C18S – izdelano do 8/2016 |
7 |
490 |
C0011 |
S0940 |
|
C18S – izdelano od 9/2016 |
5 |
490 |
C0011 |
S0940 |
|
KC35S, AC32SP(L), KC32SP(L) |
6 |
490 |
C0011 |
S0940 |
|
C25ST, C25SP(L) |
6 |
490 |
C0011 |
S0940 |
|
C20, C20S, AC35S |
9 |
490 |
C0011 |
S0940 |
|
C30, C30S, AC45S, KC45S |
10 |
590 |
C0013 |
S0940 |
|
C32ST |
8 |
590 |
C0013 |
S0940 |
|
C40, C40S |
11 |
690 |
C0014 |
S0940 |
|
C50S |
11 |
650 |
C0015 |
S0940 |
|
DC14R |
4 |
490 |
C0067 |
S0940 |
|
DC24RS, DC30RS |
3 |
490 |
C0068 |
S0940 |
|
Vrsta kotla ATMOS |
Kocka v sprednjem delu |
Kocka v zadnji del |
Keramični rob rešetke |
|
C15S, C18, KC16S C18S – izdelano do 8/2016 (7 rešetk) |
C0021 |
C0021 |
|
|
C20, C20S, AC35S |
C0022 |
C0022 |
|
|
C30, C30S, AC45S, KC45S, C25ST, C25SP(L), KC35S, AC32SP(L), KC32SP(L), C80S |
C0023 |
C0023 |
|
|
C32ST |
C0030 |
C0030 |
|
|
C40, C40S, C50S |
C0024 |
C0023 |
|
|
AC25S, KC25S, C18SP(L), AC25SP(L), KC25SP(L) C18S – izdelano od 9/2016(5 rešetk) |
C0026 |
C0026 |
|
|
DC14R |
DC0019 |
DC0019 |
DC0155(2xDC0154) – rob rešetke DC0145(2xDC0144) – vložka kurišča |
|
DC24RS, DC30RS |
DC0020 |
DC0019 |
DC0156 (levi bok), DC0157 (desni bok) |
